Luminous Letter Milling Cutter

The Luminous Letter Milling Cutter produced by Zhongyeda supports customization. There are many products that we can make, such as:

Single-edge spiral taper end mill

Features: no smoke and odor during processing, fast speed, high efficiency, no sticky chips, and can achieve environmental protection effects. Its special manufacturing process can ensure that there is no cracking when processing acrylic, and the knife marks are extremely fine or even without knife marks, making the surface smooth and flat.

Scope of application: Mainly used for cutting and processing of acrylic materials, suitable for making panels for luminous characters, etc., and can accurately cut out acrylic luminous character components of various shapes and sizes.

Material: Usually made of hard materials such as tungsten steel alloy, it has high hardness and wear resistance, can maintain good cutting performance and extend the service life of the tool.

Specifications: Common specifications include shank diameter 12mm, length 28mm, tool tip 1.5mm, helix angle 60°and other specifications, which can be selected according to different engraving machine models and processing requirements.

Double-edged spiral milling cutter

Features: It has two chip removal grooves, and the double-edged design gives it good chip removal function and tool self-balancing ability. It can effectively reduce the vibration of the tool during processing and improve processing accuracy.

Scope of application: Suitable for cutting and engraving of various materials, such as density board, wood, etc. When making luminous characters, it can be used for cutting the outline of the characters, grooving and other processes, and has a better processing effect on luminous character structural parts that require certain strength and stability.

Material: Generally made of high-speed steel or carbide. High-speed steel has better toughness and is suitable for processing some softer materials; carbide has higher hardness and stronger wear resistance, and can be used to process materials with higher hardness.

Specifications: There are various diameters and lengths to choose from, such as 6mm, 8mm, 10mm, etc., and the length ranges from 20mm to 50mm to meet different processing depths and size requirements.

Flat-bottomed sharp knife

Features: The tip of the knife is flat-bottomed and the blade is tapered, which can form clear edges and sharp angles during the engraving process.

Scope of application: Commonly used for engraving of materials such as two-color boards, PVC boards, plexiglass, ABS boards, etc., can be used to make three-dimensional effects of luminous characters, engrave details of characters, etc., such as engraving three-dimensional strokes and decorative lines on the surface of the characters, etc.10.

Material: Tungsten steel or carbide is mostly used to ensure the sharpness and durability of the tool, and can be finely engraved on different materials.

Specifications: The tip angle usually has different options such as 60°and 90°, and the tool diameter and length also have a variety of specifications, such as diameter 3mm, 5mm, length 25mm, 30mm, etc., which can be matched according to specific engraving needs.

Ball-end milling cutter

Features: The tool head is spherical, and the blades are distributed around the ball head, which can realize the engraving and processing of curved surfaces. During the processing, the contact area between the tool and the workpiece can be reduced, the cutting force can be reduced, and excessive cutting and damage of the material can be avoided.

Scope of application: It is suitable for large-scale deep relief processing of materials such as cork, density board, native wood, PVC, acrylic, etc. When making luminous characters, it can be used to make luminous character parts with arcs, circles or irregular surfaces, such as some artistic characters, curved surface shapes of three-dimensional characters, etc.

Material: Mainly made of cemented carbide or tungsten steel, it has good wear resistance and corrosion resistance, and can maintain stable cutting performance during long-term processing.

Specifications: The ball head diameter has a variety of sizes, such as 6mm, 8mm, 10mm, etc. The tool length is generally between 30mm and 60mm, which can be selected according to different surface radius and processing depth requirements.

Corn milling cutter

Features: The blade shape is similar to corn, with multiple cutting edges and chip grooves, which can effectively disperse the cutting force during the cutting process, improve cutting efficiency, and remove chips smoothly to reduce chip accumulation.

Scope of application: Commonly used in the processing of bakelite boards, carbon fiber boards, solid materials and other materials. In the production of luminous letters, it can be used for rough processing of some materials with high hardness and large-area cutting, such as cutting the bottom plate of luminous letters, etc.9.

Material: Generally, cemented carbide or coated cemented carbide is used to improve the hardness, wear resistance and corrosion resistance of the tool to meet the processing needs of different materials.

Specifications: The tool diameter is usually between 6mm and 20mm, and the length ranges from 30mm to 80mm. The appropriate specifications can be selected according to the specific material thickness and processing requirements.

The stability and safety shown by the Luminous Letter Milling Cutter during the processing process ensure that every cutting can achieve the ideal effect. The processed luminous letters have smooth edges and evenly scattered light, creating a bright and uniform visual effect, adding a unique charm to the city night scene.

Luminous Letter Milling Cutter has become an indispensable professional tool in the modern advertising and decoration industry with its excellent cutting performance, wide range of applications and efficient production capacity. Whether it is a commercial block, a shopping mall or a cultural landmark, Luminous Letter Milling Cutter is silently contributing its strength to add luster to the beautification and lighting projects of the city.

Zhongyeda Luminous Letter Milling Cutter, a professional-grade cutting tool tailored for the production of LED luminous letters, plays a vital role in advertising signs, commercial displays and indoor and outdoor decoration industries with its excellent performance and exquisite craftsmanship. This milling cutter integrates the latest achievements of material science and precision machinery technology, bringing unprecedented efficiency and quality improvement to the production of luminous letters.
